$18,445.00
| Voltage | AH/kVA | Length | Width | Height | Weight |
|---|---|---|---|---|---|
| 6 kVA / 4.2 kW | 200–240 VAC, | 28.7–28.8 in | 19 in | 17.5 in | 1845 |
| Voltage | 6 kVA / 4.2 kW |
| Amp/H | 200–240 VAC, |
| Length | 28.7–28.8 in |
| Width | 19 in |
| Height | 17.5 in |
| Weight | 1845 |
Symmetra RM delivers scalable, modular on-line protection for rack systems. The TF6 kit adds a
4-wire 120/240 V transformer for panel/hard-wired distribution while the UPS electronics remain
208/240 V. Each refurbished unit is fully reconditioned, cosmetically refreshed, and
tested in the USA for dependable, ready-to-deploy service.
| Category | Detail |
|---|---|
| Power & Topology | 6 kVA / 4.2 kW; true double-conversion on-line; modular N+1 architecture (power, battery, intelligence modules) |
| Input | 200–240 VAC, 3-wire (L1-L2-G); 50/60 Hz (typ. 57–63 Hz window); configurable for 208 or 240 V nominal; hard-wire or L6-30P by build |
| Output | 120/240 VAC, 4-wire (L1-N-L2-G) via TF6 transformer for panel/hard-wired distribution; supports 208/240 VAC use cases per configuration |
| Bypass | Integrated static bypass; internal maintenance bypass switch on frame; external wrap-around MBB optional |
| Short-Circuit / AIC | Site-specific; coordinate with upstream/downstream protection and the project one-line |
| Battery System | Hot-swappable SYBT2 VRLA modules (base unit ships with 3 modules); extend runtime with XR frames (SYRMXR2B4/SYRMXR4B4) |
| Controls & Comm | PowerView RM LCD; SmartSlot accessory bay; optional SNMP/web, RS-485/Modbus, and dry-contact/relay cards |
| Physical | 17.5 in height; 19 in width; ≈28.7–28.8 in depth; rack rails/brackets included (by kit) |
| Environment | Indoor, temperature-controlled location; install per OEM ventilation/clearance guidance |
| Accessory | Model | Notes |
|---|---|---|
| 4-Wire Transformer Kit | TF6 | Provides 120/240 V (L1-N-L2-G) hard-wire output for panel distribution |
| Step-Down PDU Transformer | TF3 | 208→120 V PDU with (4) L5-20R receptacles (alternate bundle) |
| XR Battery Frames | SYRMXR2B4 / SYRMXR4B4 | 4U external frames for additional SYBT2 modules; extend runtime |
