APC – AP8858NA3 – Metered – PDU – Tested

Manufacturer

OEM Part Number

AP8858NA3

GPS Part Number

AP8858NA3

Tags

Price:

$716.99

Specifications
View Spec Sheet
Voltage AH/kVA Length Width Height Weight
208 VAC 3,300 VA 35.51in 2.20in 1.73in 6.46lb
Voltage 208 VAC
Amp/H 3,300 VA
Length 35.51in
Width 2.20in
Height 1.73in
Weight 6.46lb

APC NetShelter — Metered Rack PDU (AP8858NA3)

This is the Tested Version.

SKU: PDU-APC-AP8858NA3  |
Type: 0U vertical, Metered (2G) rack PDU for 200/208/230/240 V single-phase racks. Delivers up to
3.3 kVA with a local LCD (amps, volts, kW, kWh) and remote monitoring; outlet layout 18 × C13 + 2 × C19;
locking NEMA L6-20P input on a 9.84 ft (3.00 m) cord.

  • Outlet mix: 18 × IEC 60320 C13 + 2 × IEC 60320 C19 (total 20).
  • Input: 200/208/230/240 V single-phase via L6-20P; 9.84 ft (3.00 m) cord; 50/60 Hz.
  • Metered visibility: Outlet group metering with ±3% accuracy; user-defined thresholds; secure Web/SNMP/Telnet access; temp/humidity sensor port.
  • Zero-U vertical, half-height: 35.51 in high (fits short racks); toolless brackets included.
  • Data-center ready: UL/CSA/IEC listed; operating −5–60 °C, 5–95% RH (non-condensing).

Technical Specifications — AP8858NA3
Parameter Detail
PDU Type Metered, 2G; Zero-U vertical (0U)
Input 200/208/230/240 VAC; NEMA L6-20P; cord length 9.84 ft (3.00 m); 1 power cord
Line Rated / Max Input Current 16 A line-rated  |  20 A input limit
Output Voltage 208 VAC
Outlets 18 × C13  |  2 × C19 (total 20)
Load Capacity 3,300 VA
Frequency 50/60 Hz
Dimensions (H×W×D) 35.51 × 2.20 × 1.73 in (90.2 × 5.6 × 4.4 cm)
Net / Ship Weight 6.46 lb (2.93 kg)  |  Ship wt. ~10.85 lb (4.92 kg)
Included Hardware Toolless rack mounting brackets; locking input power cord; serial configuration cable; installation & safety guides
Certifications METI Denan; VDE
Standards UL 60950-1; CSA C22.2 No. 60950; IEC 60950
Environment Operating: 23–140 °F (−5–60 °C), 5–95% RH; Altitude 0–10,000 ft
Storage: −13–149 °F (−25–65 °C), 5–95% RH; Altitude 0–50,000 ft
Warranty (mfr.) 2-year repair or replace

Notes & Replacement

AP8858NA3 is a current half-height 0U Metered (2G) PDU (20 outlets, 20 A L6-20P). Need more outlets or 30 A capacity?
See AP8841 (0U, 30 A, 36 × C13 + 6 × C19) or, for 3-phase mixed-voltage racks, AP8863 (0U, 20 A, 120/208 V 3φ).

Product Options — Tested vs. Refurbished PDUs
Option Description Warranty
Tested Operationally verified: load checks on all C13/C19 outlets; cord/plug inspection; LCD metering verified; thresholds/alarm check. 90‑Day
Refurbished Cleaned and serviced unit; cosmetic touch-ups as needed; full outlet and meter re-verification after service. 1‑Year

  • Use case: 208 V racks needing a compact (half-height) 0U PDU with metering and alarm thresholds.
  • Visibility: Real-time LCD + remote Web/SNMP/Telnet → plan capacity and avoid trips.
  • Space: Zero-U vertical mounting preserves 19″ rack units for gear.

Compatibility & Variants Matrix
Model Input / Plug Outlets Rating / Notes
AP8858NA3 200/208/230/240 V 1φ / NEMA L6-20P (9.84 ft) 18 × C13; 2 × C19 Metered 2G; 0U (half-height); 3.3 kVA; 16 A line-rated (20 A max).
AP8841 200/208 V 1φ / NEMA L6-30P (9.84 ft) 36 × C13; 6 × C19 Metered 2G; 0U (full-height); 5.0 kW; 24 A line-rated (30 A max).
AP8863 120/208 V 3φ / NEMA L21-20P 24 × NEMA 5-20R; 6 × NEMA L6-20R Metered 2G; 0U; mixed 120/208 V 3-phase distribution.

Why buy from Gruber
  • Professionally tested — Outlets and metering verified under load; ground/continuity checks documented.
  • Exact fit hardware — Ships with the correct Zero-U brackets and accessories.
  • Fleet-ready — Mixed C13/C19 supports a wide range of 208 V IT gear.
