$18,445.00
| Voltage | AH/kVA | Length | Width | Height | Weight |
|---|---|---|---|---|---|
| 208/120 | 60 KVA | 36" | 29.02" | 80.98" | 1,631 lb |
| Voltage | 208/120 |
| Amp/H | 60 KVA |
| Length | 36" |
| Width | 29.02" |
| Height | 80.98" |
| Weight | 1,631 lb |
Built to simplify distribution for medium/large IT rooms, this InfraStruXure PDU steps 480 V down to 208/120 V and integrates a maintenance bypass for serviceability. Our refurbished units are reconditioned, cosmetically refreshed to factory colors, and tested in the USA for reliable, ready-to-deploy service.
| Category | Detail |
|---|---|
| Power & Architecture | 80 kW configurable distribution PDU with integrated 480→208/120 V isolation transformer; floor-standing cabinet |
| Input | 480 V 3-phase, 60 Hz nominal |
| Output | 208Y/120 V 3-phase distribution via modular PDMs; receptacle mix and breaker layout per configuration |
| Bypass | Integrated Maintenance Bypass Panel (MBP) for service without downtime |
| Monitoring & Alarms | Local display; network/remote monitoring options available for the InfraStruXure PDU family |
| Physical | ≈ 80.98″ H × 29.02″ W × 36.0″ D; ≈ 1,631 lb (≈ 740 kg) cabinet |
| Environment | 0–40 °C operating; 0–95% RH (non-condensing); ≤ 3,333 ft operating altitude (family spec) |
| Standards | UL / cUL (model family); black finish |
| Accessory | Model | Notes |
|---|---|---|
| IT Power Distribution Module (PDM) | Examples: PDM3520IEC309-80, PDM3530L21-30 | Hot-swappable modules; common outputs include IEC 309, L21-20R, L6-30R (mix varies by build) |
| Cable/Extender Kit | PD Cable Extender | Installation accessory for PD-series PDUs |
| Branch Circuit Options | — | Configured to order (receptacle plates and/or hard-wired sub-feeds) |
