APC – AP9567 – PDU – Tested

Manufacturer

OEM Part Number

AP9567

GPS Part Number

AP9567

Tags

Price:

$262.99

Specifications
View Spec Sheet
Voltage AH/kVA Length Width Height Weight
100/120VAC 1400 VA 24.02in 1.70in 1.70in 4.81lb
Voltage 100/120VAC
Amp/H 1400 VA
Length 24.02in
Width 1.70in
Height 1.70in
Weight 4.81lb

APC NetShelter โ€” Basic Rack PDU (AP9567)

This is the Tested Version.

SKU: PDU-APC-AP9567 ย |
Type: 0U vertical, Basic (non-metered) rack PDU for 100/120ย V single-phase racks.
Delivers up to 1.4ย kVA with 14ย ร—ย NEMAย 5-15R outlets; locking NEMAย 5-15P input on a
12ย ft (3.7ย m) cord. Short vertical form factor (24ย in) for compact racks.

  • Outlet set: 14ย ร—ย NEMAย 5-15R (120ย V) for general IT loads.
  • Input: NEMAย 5-15P; single 12ย ft (3.7ย m) line cord; 50/60ย Hz.
  • Basic design: No local metering or switching โ€” simple, reliable 120ย V distribution.
  • Zero-U vertical: Toolless NetShelter brackets included; preserves rack U-space.
  • Data-center ready: UL/cUL & METI Denan; operating 32โ€“113ย ยฐF (0โ€“45ย ยฐC), 0โ€“95% RH.

Technical Specifications โ€” AP9567
Parameter Detail
PDU Type Basic; Zero-U vertical (0U)
Input 100/120ย VAC; NEMAย 5-15P; 1 power cord; length 12ย ft (3.7ย m)
Line Rated / Max Input Current 12ย A line-rated ย |ย  15ย A input limit
Output Voltage 100/120ย VAC
Outlets 14ย ร—ย NEMAย 5-15R
Load Capacity 1,400ย VA
Frequency 50/60ย Hz
Dimensions (H ร— W ร— D) 24.02 ร— 1.70 ร— 1.70ย in (610 ร— 44 ร— 44ย mm)
Net / Ship Weight 4.81ย lb (2.18ย kg) ย |ย  ~6.44ย lb (2.92ย kg) packaged
Form Factor / Mounting 0U; rack-mounted; vertical; mounting location side; no preference
Included Hardware Installation guide; rack mounting brackets; toolless mounting kit
Certifications ULย Listed; cULย Listed; METIย Denan
Environment Operating: 32โ€“113ย ยฐF (0โ€“45ย ยฐC), 0โ€“95% RH; Altitude 0โ€“10,000ย ft
Storage: โˆ’13โ€“149ย ยฐF (โˆ’25โ€“65ย ยฐC), 0โ€“95% RH; Altitude 0โ€“50,000ย ft
Warranty (mfr.) 2-year repair or replace

Notes & Replacement

AP9567 is a short vertical Basic 0U PDU (no metering). Need a 120ย V unit with a local amp display? See
AP7800B (1U, 8ร— 5-15R). Need a full-height 0U metered IEC model for 200/208ย V? See AP8841 (30ย A, 36ร— C13 + 6ร— C19).

Product Options โ€” Tested vs. Refurbished PDUs
Option Description Warranty
Tested Cord/plug inspection; ground & continuity checks; load test across all 5-15R outlets; bracket fit verified. 90โ€‘Day
Refurbished Cleaned and serviced; cosmetic touch-ups as needed; full outlet re-verification after service. 1โ€‘Year

  • Use case: Simple 120ย V distribution in compact or short racks (24″ vertical run).
  • Space: Zero-U mounting preserves 19″ rack units for gear.
  • Install tip: Observe 12ย A continuous derate (80% of 15ย A max) and secure cords with the included bracketry.

Compatibility & Variants Matrix โ€” 120ย V Rack PDUs
Model Input / Plug Outlets Rating / Notes
AP9567 100/120ย Vย 1ฯ† / NEMAย 5-15P (12ย ft) 14ย ร—ย NEMAย 5-15R Basic; 0U; 1.4ย kVA; 12ย A line-rated (15ย A max).
AP9562 100/120ย Vย 1ฯ† / NEMAย 5-15P (12ย ft) 10ย ร—ย NEMAย 5-15R Basic; 1U; 1.4ย kVA; shorter cord reach not required.
AP7800B 100/120ย Vย 1ฯ† / NEMAย 5-15P (12ย ft) 8ย ร—ย NEMAย 5-15R Metered; 1U alternative when local current display is needed.



Why buy from Gruber
  • Professionally tested โ€” Outlets verified under load; ground/continuity checks documented.
  • Exact fit hardware โ€” Ships with the correct Zero-U toolless brackets and install guide.
  • Fleet-ready โ€” Standard 5-15R outlets for common 120ย V IT gear.
