SEMIKRON – 12-810094-00 – IGBT Power Transistor – Reclaimed Part

Semikron — SKKT 162/16E Thyristor SCR Power Module 1600 V • 156 A I_T(AV) • Dual Thyristor-Thyristor Configuration • SEMIPACK 2

What it is

The Semikron SKKT 162/16E is an industrial-grade 1600 V, 156 A dual thyristor/SCR power module housed in the proven SEMIPACK 2 package. Designed for high-power controlled rectification and phase-control applications, the module combines two thyristor elements in a compact, heatsink-mounted assembly with an electrically isolated baseplate.

With a 250 A RMS current rating, 5000 A non-repetitive surge capability and high electrical and thermal cycling capability, the SKKT 162/16E is well suited to industrial rectifiers, motor controls, soft-start circuits, heater controls, battery chargers, welding equipment and other demanding power-conversion systems.

At-a-Glance

• Voltage Rating: 1600 V V_DRM / V_RRM
• Average On-State Current: 156 A I_T(AV) @ T_case = 85°C
• RMS On-State Current: 250 A I_TRMS
• Surge Current: 5000 A I_TSM
• I²t Rating: 125 kA²s
• Topology: Dual thyristor-thyristor SCR configuration
• Package: SEMIPACK 2 • 94 × 34 × 30 mm
• Applications: Rectifiers; soft-starts; motor controls; heater controls; battery chargers; welding equipment

Features

• 1600 V blocking capability — designed for demanding industrial power-control and rectifier circuits.
• High surge strength — I_TSM rated at 5000 A for high transient-current capability.
• High I²t capability — 125 kA²s rating provides substantial short-duration overload capability.
• Low conduction losses — 0.85 V threshold voltage with approximately 1.5 mΩ on-state slope resistance.
• Industrial thermal performance — 0.18°C/W junction-to-case thermal resistance.
• SEMIPACK 2 construction — compact, rugged package designed for direct heatsink mounting.
• Electrically isolated baseplate — simplifies mounting in high-power industrial assemblies.

Technical Specifications

Applications / Replacement Considerations
