Vishay VS-VSK.170-16 MAGN-A-PAK Thyristor Power Module – 1600V 170A – Reclaimed Part

Vishay — VS-VSK.170-16 MAGN-A-PAK Thyristor Power Module

What It Is

The Vishay VS-VSK.170-16 is a high-voltage, high-current thyristor power module from Vishay’s MAGN-A-PAK family. Designed for industrial power-control applications, it combines high surge-current capability, an electrically isolated baseplate, and rugged screw-terminal construction in a compact module package.

Depending on the exact ordering configuration, the VSK.170 family is available as SCR/SCR or SCR/Diode. The electrically isolated baseplate allows multiple modules to share a common heatsink while simplifying mechanical assembly and thermal management.

Typical applications include UPS systems, industrial motor drives, battery chargers, welding equipment, controlled rectifiers, and high-power AC/DC conversion systems.

At a Glance

• Voltage Rating: Up to 1600 V repetitive peak blocking voltage
• Average On-State Current: 170 A at T_C = 85°C
• RMS Current: 377 A
• Surge Capability: 5.10 kA at 50 Hz / 5.35 kA at 60 Hz
• Isolation: 3500 V RMS, terminals to baseplate
• Configuration: SCR/SCR or SCR/Diode depending on exact ordering suffix
• Package: Vishay MAGN-A-PAK industrial power module

Key Features

• High-voltage capability — supports applications requiring up to 1600 V repetitive blocking voltage.
• 170 A continuous current class — designed for substantial industrial load currents when properly cooled.
• Exceptional surge capability — more than 5 kA single-cycle surge current for demanding startup and fault conditions.
• Electrically isolated baseplate — simplifies heatsink design and permits compact multi-module assemblies.
• 3500 V RMS isolation — provides substantial electrical separation between semiconductor circuitry and heatsink.
• Industrial MAGN-A-PAK package — rugged screw-terminal construction designed for high-power applications.
• High dV/dt capability — rated to withstand demanding switching environments.

Technical Specifications

Why the High Surge Rating Matters

Power-conversion equipment can experience extremely high short-duration currents during capacitor charging, motor startup, transformer energization, or fault events. The VSK.170 series provides more than 5 kA of one-cycle surge capability, giving it substantial short-duration current headroom beyond its normal operating current.

Compatibility / Representative Uses
