Xtreme Power M90Ci-2S Modular UPS — 10 kW, 415/240 V or 400/230 V Three-Phase

The Xtreme Power M90Ci-2S is a compact, rackmount modular three-phase UPS designed for
environments built around modern 400 V architectures. Delivering dependable 415/240 V or 400/230 V
three-phase power, it provides true online double-conversion protection for data centers, industrial
automation systems, enterprise IT, and edge-computing sites that require efficient, serviceable backup power
in a tight footprint.

This 2-slot chassis includes one 10 kW power module and one battery module, supplying unity power factor (1.0 PF)
output and up to 94 % online efficiency (98 % in ECO mode) to minimize energy and cooling costs. The
tool-free, easy-swap power module simplifies maintenance and reduces service time—ideal for distributed
sites and smaller facilities where downtime must be kept to an absolute minimum. Certified to CE, IEC 62040,
and RoHS, the M90Ci-2S is a perfect fit for compact 400 V three-phase deployments seeking reliable,
high-density power protection.

Key Features & Benefits

• Rackmount 2-Slot Modular Design — Includes one 10 kW power module and one battery module in a compact chassis.
• 415/240 V or 400/230 V Three-Phase Operation — Compatible with modern global 400 V WYE infrastructures (also supports 380/220 V).
• High Efficiency — Up to 94 % online and 98 % in ECO mode to reduce energy use and cooling requirements.
• Unity Power Factor Output (1.0 PF) — Full 10 kW usable capacity for IT and industrial loads without derating.
• Tool-Free Power Module Replacement — Fast servicing and module swaps without complex disassembly.
• Per-Module LCD Displays — Local status, alarms, and load information on each module for quick diagnostics.
• Integrated Manual Maintenance Bypass — Allows safe transfer of the load to utility power during service.
• Hardwired Input/Output — Robust terminations for commercial and industrial installations.
• 2-Year Warranty — Electronics and battery coverage in the U.S. & Canada.

Product Snapshot

Why Choose the M90Ci-2S?

The M90Ci-2S delivers high-density 10 kW power, unity PF output, and modular serviceability in a compact rackmount form factor—making it ideal for:

• Modern 400 V three-phase systems looking for a native 400/230 V or 415/240 V UPS solution.
• Small & midsize edge-compute deployments that require efficient, reliable backup in limited rack space.
• Industrial automation and process control where minimal downtime and quick service are critical.
• Facilities migrating from legacy 208 V or 480 V architectures to higher-efficiency 400 V distributions.
