APC – Galaxy VS – 10000 – 10 kVA – Three Phase Online UPS

Galaxy VS UPS — 10 kW / 10 kVA, 400 V 3-Phase (1× 9Ah Smart Modular Battery String, Expandable to 4)

Highly efficient, easy-to-deploy 10 kW, 400 V three-phase UPS designed to deliver best-in-class power protection and low total cost of ownership for edge, small/medium data centers, and commercial & industrial critical loads. Ships with 1 internal 9Ah smart high-capacity modular battery string and supports expansion up to 4 strings for extended runtime (runtime charts available in the Documents tab).

Why these fail

• Undersizing — growth planning is skipped, leading to overloads and nuisance transfers.
• Poor power quality — high THD and unstable mains create heat, stress, and premature component aging.
• Harsh short-circuit environments — installations exceed equipment withstand or bypass capability.
• Inadequate commissioning — settings, sync modes, and bypass behavior aren’t validated under load.

Our solution

• High efficiency + low distortion — input THD < 3% at full load; output THD < 1% (linear) / < 3% (non-linear).
• Wide operating window — maintains efficiency from 340…460 V (400 V nominal range).
• Built-in static bypass — robust continuity during fault/overload scenarios.
• Scalable battery architecture — 1 string installed; expand to 4 strings when runtime demands increase.
• Included 5×8 start-up — on-site commissioning support (5 days × 8 hours) to validate configuration and operation.

Service & coverage

Start-up service is designed to help ensure proper commissioning, parameter setup, and operational verification. Runtime charts are provided in the Documents tab and vary by load and the number of installed battery strings (1–4).
