Tutorial – Liebert/Vertiv Small UPS Series Battery Matrix

Liebert copy
USA
1 Year
Liebert copy
USA
1 Year

Manufacturer

OEM Part Number

Tutorial-GXT Matrix

GPS Part Number

58-LIE-GXT-Matrix

Categories

,

Tags

, , , , , , ,

Price:

$0.00

Specifications
View Spec Sheet
Voltage AH/kVA Length Width Height Weight
0 Volts 0 Ah 19.7" 0" 0" 0 lbs
Voltage 0 Volts
Amp/H 0 Ah
Length 19.7"
Width 0"
Height 0"
Weight 0 lbs

Liebert/Vertiv GXT5 — Internal Battery Kits (VRLA)
Battery Kit (P/N) UPS Models Covered (examples) BOM per Kit String V Ah Kits / UPS
GXT5-36VBATKIT GXT5-500/750/1000 (…LVRT2UXL / IRT2UXL variants) 3 × 12 V cells 36 V 9 Ah 1
GXT5-48VBATKIT GXT5-1500/2000 (…LVRT2UXL / IRT2UXL variants) 4 × 12 V cells 48 V 9 Ah 1
GXT5-72VBATKIT GXT5-3000 (…LVRT2UXL / IRT2UXL variants) 6 × 12 V cells 72 V 9 Ah 1

Liebert/Vertiv GXT5 — External Battery Cabinets (EBC)
EBC (P/N) UPS Models Covered (examples) BOM per Cabinet String Layout Ah Cabinets
GXT5‑EBC36VRT2U GXT5‑750/1000 (…IRT/LVRT) 6 × 12 V cells 2 × (3 in‑series) 9 Ah 1–6
GXT5‑EBC48VRT2U GXT5‑1500/2000 (…IRT/LVRT) 8 × 12 V cells 2 × (4 in‑series) 9 Ah 1–6
GXT5‑EBC72VRT2U GXT5‑3000 (…IRT/LVRT) 12 × 12 V cells 2 × (6 in‑series) 9 Ah 1–6

Liebert/Vertiv GXT4 — Internal Battery Kits
Battery Kit (P/N) UPS Models Covered (examples) BOM per Kit String V Ah Kits / UPS
GXT4‑5A48BATKIT GXT4‑500/700/1000 4 × 12 V cells 48 V 5 Ah 1
GXT4‑9A48BATKIT GXT4‑1500/2000 4 × 12 V cells 48 V 9 Ah 1
GXT4‑9A72BATKIT GXT4‑3000 6 × 12 V cells 72 V 9 Ah 1
GXT4‑144VBATKIT GXT4‑5000RT208 / 6000RT208 12 × 12 V cells 144 V 9 Ah 1
GXT4‑240VBATKIT GXT4‑6000RTL630 20 × 12 V cells 240 V 5 Ah 2
GXT4‑288VBATKIT GXT4‑8000RT208 / 10000RT208 24 × 12 V cells 288 V 9 Ah 2

Liebert/Vertiv GXT4 — External Battery Cabinets (EBC)
EBC (P/N) UPS Models Covered (examples) BOM per Cabinet String Layout Ah Cabinets
GXT4‑48VBATT GXT4‑500/700/1000/1500/2000 8 × 12 V cells 2 × (4 in‑series) 9 Ah 1–6
GXT4‑72VBATT GXT4‑3000 12 × 12 V cells 2 × (6 in‑series) 9 Ah 1–6

Liebert/Vertiv GXT3 — Internal Battery Kits (use GXT4 kits per Vertiv X‑Ref)
UPS Models Battery Kit (P/N) BOM per Kit String V Ah Kits / UPS Notes
GXT3‑500/700/1000/1000MT GXT4‑5A48BATKIT 4 × 12 V cells 48 V 5 Ah 1 Per Vertiv cross‑ref
GXT3‑1500/2000 GXT4‑9A48BATKIT 4 × 12 V cells 48 V 9 Ah 1 Per Vertiv cross‑ref
GXT3‑3000 GXT4‑9A72BATKIT 6 × 12 V cells 72 V 9 Ah 1 Per Vertiv cross‑ref
GXT3‑5000/6000 (208 V) GXT4‑144VBATKIT 12 × 12 V cells 144 V 9 Ah 1 Per Vertiv cross‑ref
GXT3‑8000/10000 (208 V) GXT4‑288VBATKIT 24 × 12 V cells 288 V 9 Ah 2 Per Vertiv cross‑ref

Liebert/Vertiv GXT3 — External Battery Cabinets (EBC)
EBC (P/N) UPS Models Covered (examples) BOM per Cabinet String Layout Ah Cabinets
GXT3‑48VBATT GXT3‑700/1000/1500/2000 (typ.) 8 × 12 V cells 2 × (4 in‑series) 9 Ah 1–6
GXT3‑72VBATT GXT3‑3000 (typ.) 12 × 12 V cells 2 × (6 in‑series) 9 Ah 1–6

Liebert/Vertiv GXT2 — Internal Battery Kits
Battery Kit (P/N) UPS Models Covered (examples) BOM per Kit String V Ah Kits / UPS
GXT2‑7A48BATKIT GXT2‑500/700/1000/1500 4 × 12 V cells 48 V 7–7.2 Ah 1
GXT2‑9A48BATKIT GXT2‑2000 4 × 12 V cells 48 V 9 Ah 1
GXT2‑9A72BATKIT GXT2‑3000 / 2700RT208 6 × 12 V cells 72 V 9 Ah 1

Liebert/Vertiv GXT2 — External Battery Cabinets (EBC)
EBC (P/N) UPS Models Covered (examples) BOM per Cabinet String Layout Ah Cabinets
GXT2‑48VBATT GXT2‑500/700/1000/1500/2000 8 × 12 V cells 2 × (4 in‑series) 7–7.2 Ah 1–6
GXT2‑72VBATT GXT2‑3000 / 2700RT208 12 × 12 V cells 2 × (6 in‑series) 9 Ah 1–6

Liebert/Vertiv GXT RT+ (230 V) — Internal Battery Kits
Battery Kit (P/N) UPS Models Covered BOM per Kit String V Ah Kits / UPS
GXTRT‑24BATKIT GXTRT‑1000IRT2UXL 2 × 12 V cells 24 V 9 Ah 1
GXTRT‑36BATKIT GXTRT‑1500IRT2UXL 3 × 12 V cells 36 V 9 Ah 1
GXTRT‑48BATKIT GXTRT‑2000IRT2UXL 4 × 12 V cells 48 V 9 Ah 1
GXTRT‑72BATKIT GXTRT‑3000IRT2UXL 6 × 12 V cells 72 V 9 Ah 1
VRLA12 V blocksHot‑swappablePer‑kit BOM shown
  • BOM = bill of materials inside each battery kit/cabinet (count of 12 V blocks × their Ah). External cabinet counts are per cabinet.
  • “Kits / UPS” shows how many kits the UPS requires (e.g., GXT4 8–10 kVA uses two internal kits).
  • Model lists are representative; check your exact suffix (LV/IRT voltage, plug set, regional variant) when ordering.

Notes & verification

  1. GXT5 internal kits & compat: Vertiv literature lists GXT5‑36/48/72VBATKIT for the 500–3000 VA models.
  2. GXT5 EBC BOM: Vertiv’s EBC guide shows cabinet totals (EBC36=6, EBC48=8, EBC72=12 batteries).
  3. GXT4 internal kits: 5A48 (4×12 V 5 Ah), 9A48 (4×12 V 9 Ah), 9A72 (6×12 V 9 Ah), 144VBATKIT (12×12 V 9 Ah), 240VBATKIT (20×12 V 5 Ah), 288VBATKIT (24×12 V 9 Ah).
  4. GXT4/GXT3 EBCs: 48VBATT = 8 cells as 2×(4 in series); 72VBATT = 12 cells as 2×(6 in series).
  5. GXT3 uses GXT4 kits: Official cross‑reference maps GXT3 to GXT4 kits; high‑kVA models require two internal kits.
  6. GXT2 internals & EBCs: GXT2 manuals list 4×12 V×7–7.2 Ah, 4×12 V×9 Ah, 6×12 V×9 Ah internally; cabinets are 2×(4) and 2×(6) layouts.
  7. GXT RT+ (230 V): Brochures show GXTRT‑24/36/48/72BATKIT mapped to the 1–3 kVA line with 2/3/4/6 cells respectively.

Lithium‑ion note: GXT5 LI models (e.g., GXT5LI‑1000/1500/3000) use different battery kits; if needed, I can append a LI section.
