| Voltage | WPC | AH/kVA | Length | Width | Height | Weight |
|---|---|---|---|---|---|---|
| 0 Volts | N/A | 0 Ah | 19.7" | 0" | 0" | 0 lbs |
| Voltage | 0 Volts |
| WPC | N/A |
| Amp/H | 0 Ah |
| Length | 19.7" |
| Width | 0" |
| Height | 0" |
| Weight | 0 lbs |
| Battery Cartridge (P/N) | UPS Models Covered (examples) | BOM per Cartridge | String V | Ah | Kits / UPS |
|---|---|---|---|---|---|
| 744‑A3296 | 9PX1000GRT | ≈ 4 × 12 V blocks (pre‑assembled) | 48 V | 7–9 Ah (typ.) | 1 |
| 744‑A3297 | 9PX1500RT / 9PX1500RTN / 9PX1500GRT | ≈ 4 × 12 V blocks (pre‑assembled) | 48 V | 9 Ah (typ.) | 1 |
| 744‑A3121 | 9PX2000RT / 9PX2000RTN / 9PX2200GRT | ≈ 6 × 12 V blocks (pre‑assembled) | 72 V | 9 Ah (typ.) | 1 |
| 744‑A3122 | 9PX3000RT / 9PX3000RTN / 9PX3000GRT / 9PX3000GLRT | 6 × 12 V blocks | 72 V | 9 Ah | 1 |
| EBM (P/N) | UPS Models Covered (examples) | BOM per Cabinet | String Layout | Ah | Cabinets |
|---|---|---|---|---|---|
| 9PXEBM48RT (2U) | 9PX1000GRT / 9PX1500RT/RTN/GRT | 8 × 12 V blocks (via 2 × RBC 744‑A3297) | 2 × (4 in‑series) | 9 Ah (typ.) | 1–4 |
| 9PXEBM72RT (2U) | 9PX2000RT/RTN / 9PX2200GRT / 9PX3000RT/RTN/GRT/GLRT | 12 × 12 V blocks (via 2 × RBC 744‑A3121/3122) | 2 × (6 in‑series) | 9 Ah | 1–4 |
| 9PXEBM180RT (3U) | 9PX 5–6 kVA (ex: 9PX6KUS, 9PX6KSP) | 30 × 12 V blocks | 2 × (15 in‑series) | 5 Ah | 1–4 |
| 9PXEBM360SP | 9PX 8–10 kVA Split‑Phase (ex: 9PX10KSP) | — | — | — | 1–4 (typ.) |
| Battery Cartridge (P/N) | UPS Models Covered | BOM per Cartridge | String V | Ah | Kits / UPS |
|---|---|---|---|---|---|
| 744‑A4311 | 9SX1000 / 9SX1000G | 3 × 12 V blocks | 36 V | 9 Ah (typ.) | 1 |
| 744‑A4312 | 9SX1500 / 9SX1500G | 4 × 12 V blocks | 48 V | 9 Ah (typ.) | 1 |
| 744‑A4313 (aka EBP‑0206) | 9SX2000 / 9SX2000G / 9SX3000 / 9SX3000G / 9SX3000GL / 9SX3000HW | 8 × 12 V blocks | 96 V | 9 Ah | 1 |
| EBM (P/N) | UPS Models Covered (examples) | BOM per Cabinet | String Layout | Ah | Cabinets |
|---|---|---|---|---|---|
| 9SXEBM36 (tower) | 9SX1000 / 9SX1000G | 6 × 12 V blocks | 2 × (3 in‑series) | 9 Ah | 1–4 |
| 9SXEBM48 (tower) | 9SX1500 / 9SX1500G | 8 × 12 V blocks | 2 × (4 in‑series) | 9 Ah | 1–4 |
| 9SXEBM96 (tower) | 9SX2000 / 9SX2000G / 9SX3000 / 9SX3000G / 9SX3000GL / 9SX3000HW | 16 × 12 V blocks | 2 × (8 in‑series) | 9 Ah | 1–4 |
| Form Factor / Rating | UPS Models (examples) | Internal BOM | String V | Ah | Notes |
|---|---|---|---|---|---|
| Tower — 1000 VA | PW9130L1000T‑XL | 3 × 12 V blocks | 36 V | 9 Ah | Up to 4 EBMs supported |
| Tower — 1500 VA | PW9130L1500T‑XL | 4 × 12 V blocks | 48 V | 9 Ah | Up to 4 EBMs supported |
| Tower — 2000–3000 VA | PW9130G3000T‑XL / XLEU | 8 × 12 V blocks | 96 V | 9 Ah | Up to 4 EBMs supported |
| Rack — 700–1000 VA | PW9130N1000R‑XL2U | 3 × 12 V blocks | 36 V | 9 Ah | — |
| Rack — 1500 VA | PW9130N1500R‑XL2U | 4 × 12 V blocks | 48 V | 9 Ah | — |
| Rack — 2000–3000 VA | PW9130N3000R‑XL2U | 6 × 12 V blocks | 72 V | 9 Ah | — |
| EBM (P/N) | UPS Models Covered (examples) | BOM per Cabinet | String Layout | Ah | Cabinets |
|---|---|---|---|---|---|
| PW9130N1000T‑EBM (tower) | 9130 1000 VA (tower) | 6 × 12 V blocks | 2 × (3 in‑series) | 9 Ah | 1–4 |
| PW9130N1500T‑EBM (tower) | 9130 1500 VA (tower) | 8 × 12 V blocks | 2 × (4 in‑series) | 9 Ah | 1–4 |
| PW9130N3000T‑EBM (tower) | 9130 2000–3000 VA (tower) | 16 × 12 V blocks | 2 × (8 in‑series) | 9 Ah | 1–4 |
| PW9130N1000R‑EBM2U (2U) | 9130 700–1000 VA (rack) | 6 × 12 V blocks | 2 × (3 in‑series) | 9 Ah | 1–4 |
| PW9130N1500R‑EBM2U (2U) | 9130 1500 VA (rack) | 8 × 12 V blocks | 2 × (4 in‑series) | 9 Ah | 1–4 |
| PW9130N3000R‑EBM2U (2U) | 9130 2000–3000 VA (rack) | 12 × 12 V blocks | 2 × (6 in‑series) | 9 Ah | 1–4 |
