$19.99
| Voltage | AH/kVA | Length | Width | Height | Weight |
|---|---|---|---|---|---|
| 24 VDC | 0.65 A | 4.69" | 1.51" | 4.69" | 0.57 lbs |
| Voltage | 24 VDC |
| Amp/H | 0.65 A |
| Length | 4.69" |
| Width | 1.51" |
| Height | 4.69" |
| Weight | 0.57 lbs |
MINEBEA NMB-MAT DC cooling fan commonly used in UPS power drawers and inverter bays. Provides dependable airflow across rectifiers, IGBTs, and heat-sink assemblies. Direct-fit replacement with industry-standard mounting pattern.
The 4715KL-05W-B59 variant is a 12 VDC, ball-bearing model in the 120 mm class. Please verify voltage, connector, and lead count against your OEM part before ordering.
Removed from a functioning UPS, cleaned, inspected, and bench-tested for stable RPM and current draw.
| Option | Description | Warranty |
|---|---|---|
| Brand New | Factory-new NMB-MAT fan; unopened and covered by manufacturer warranty (when available). |
1-Year
|
| Tested | Operationally verified fan removed from a functioning UPS; rotation confirmed; current draw and bearing noise checked; cleaned and leads/connector inspected. |
90-Day
|
| Part # | Dimensions | Voltage | Airflow Class | Bearing / Leads | Application |
| 4715KL-05W-B59 | Approx. 120 × 120 × 38 mm (4.72″ × 4.72″ × 1.50″) | 12 V DC | High-output axial DC fan (120 mm class) | Ball-bearing; lead/connector per variant — verify harness/pinout | UPS chassis / inverter bay / heat-sink cooling |
| Part # | Compatible Models | Notes |
| 4715KL-05W-B59 | UPS systems using 120 mm 12 VDC fans | Verify airflow direction, mounting pattern, connector/lead count vs. OEM part. |
