$15,991.25
| Voltage | WPC | AH/kVA | Length | Width | Height | Weight |
|---|---|---|---|---|---|---|
| 208/120 | N/A | 40 kVA | 33" | 56" | 79" | 4,200–4,800 lb |
| Voltage | 208/120 |
| WPC | N/A |
| Amp/H | 40 kVA |
| Length | 33" |
| Width | 56" |
| Height | 79" |
| Weight | 4,200–4,800 lb |
The Liebert 600T 225 kVA is a legacy, industrial-grade on-line UPS used across data centers and heavy commercial sites. Our refurbished units are fully reconditioned, cosmetically refreshed to factory finish, and tested in the USA for reliable, ready-to-deploy service.
| Category | Detail |
|---|---|
| Power & Topology | 225 kVA (≈180 kW); true double-conversion on-line; sine-wave output |
| Input | 208/480/600 VAC, 3-phase (3- or 4-wire + G); voltage range +10%/−15% (no battery discharge at −20%); 60 Hz ±5%; rectifier walk-in ≈20 s; optional input filter reduces THDi and raises input PF |
| Output | 208 or 480/600 VAC, 3-phase, 4-wire + G; static regulation ±0.5% (balanced), ±1% (100% unbalanced); dynamic regulation typically within ±2.5–5% for 100% step, recovers to ±1% in ~1 cycle; VTHD ≈1% (linear), <2.5% at 100% non-linear; frequency regulation ±0.1%; overload 125% for 10 min / 150% for 1 min |
| Bypass | Static bypass; external wrap-around maintenance bypass cabinet (MBB) available |
| Short-Circuit / AIC | Coordinate per site one-line and protective device study (varies by installation) |
| Battery System | External VRLA battery plant; nominal DC bus ≈480 V; required battery disconnect rating 500 A; max battery current at end of discharge ≈486–488 A (by voltage/configuration) |
| Controls & Comm | System control/operator panel with mimic/status; options for RS-232, SiteScan, SNMP/web, Modbus/RS-485, and dry-contact I/O; remote status panel available |
| Physical | Approx. 56 × 33 × 79 in (W×D×H) cabinet; weight typically ~4,200–4,800 lb depending on options; top/bottom cable entry variants |
| Environment | Indoor, controlled environment; typical operation 0–40 °C; ≤95% RH non-condensing; provide clearances per site planning (≈2 ft above unit) |
| Accessory | Model | Notes |
|---|---|---|
| Maintenance Bypass Cabinet | MBB (3-breaker) | Wrap-around service bypass for maintenance |
| Bypass Transformer Cabinet | BTC (100–225 kVA) | Isolation/step-down as required by site |
| Battery Power Pack | Size A (100–225 kVA) | Line-up-and-match battery cabinet(s); runtime scales with AH & cabinet count |
