$358.99
| Voltage | AH/kVA | Length | Width | Height | Weight |
|---|---|---|---|---|---|
| 208VAC | 4,992VA | 1.73in | 17.52in | 3.03in | 5.62lb |
| Voltage | 208VAC |
| Amp/H | 4,992VA |
| Length | 1.73in |
| Width | 17.52in |
| Height | 3.03in |
| Weight | 5.62lb |
SKU: PDU-APC-AP9571A Â |
Type: 1U horizontal, Basic (non-metered) rack PDU for 200/208/230–240 V single-phase racks. Delivers up to 4.99 kVA via 10 × IEC C13 outlets; locking NEMA L6-30P input on a 12 ft (3.7 m) cord.
| Parameter | Detail |
|---|---|
| PDU Type | Basic; 1U horizontal (rack-mount) |
| Input | 200/208/230–240 VAC; NEMA L6-30P; 1 power cord; length 12 ft (3.7 m) |
| Line Rated / Max Input Current | 24 A line-rated  | 30 A maximum |
| Output Voltage | 208Â VAC |
| Outlets | 10Â Ă—Â IECÂ 60320Â C13 |
| Load Capacity | 4,992 VA (≈5.0 kVA class) |
| Frequency | 50/60Â Hz |
| Dimensions (H Ă— W Ă— D) | 1.73 Ă— 17.52 Ă— 3.03Â in (44 Ă— 445 Ă— 77Â mm) |
| Net / Ship Weight | 5.62Â lb (2.55Â kg) Â |Â ~8.02Â lb (3.64Â kg) packaged |
| Mounting | Rack-mounted; front or rear; no preference |
| Included Hardware | Installation guide; rack mounting brackets; user manual |
| Certifications / Standards | ULÂ Listed; cULÂ Listed; PSE Â |Â ULÂ 60950 |
| Environment | Operating: 23–113 °F (−5–45 °C), 5–95% RH; Altitude 0–15,000 ft Storage: −13–149 °F (−25–65 °C), 5–95% RH; Altitude 0–50,000 ft |
| Warranty (mfr.) | 2-year repair or replace |
AP9571A is a current 1U Basic 208Â V PDU (10Â Ă—Â C13, L6-30P, 30Â A max). If you need local metering at 120Â V in 1U, see AP7800B. For 0U vertical metering at 208Â V single-phase, see AP8841; for outlet-level metering & switching, see AP8641.
| Option | Description | Warranty |
|---|---|---|
| Tested | Cord/plug inspection (L6-30P), continuity & ground checks, and load checks across all C13 outlets. | 90‑Day |
| Refurbished | Cleaned and serviced unit with cosmetic touch-ups; full outlet re-verification after service. | 1‑Year |
| Model | Input / Plug | Outlets | Rating / Notes |
|---|---|---|---|
| AP9571A | 200–240 V 1φ / NEMA L6-30P (12 ft) | 10 × IEC C13 | Basic; 1U; 4.99 kVA; 24 A line-rated (30 A max). |
| AP8841 | 200/208 V 1φ / NEMA L6-30P | 36 × C13; 6 × C19 | Metered 2G; 0U vertical; 5.0 kW; remote monitoring. |
| AP8641 | 200/208/230 V 1φ / NEMA L6-30P | 21 × C13; 3 × C19 | Metered-by-Outlet w/ Switching; 0U; outlet-level control. |
