APC – AP9567 – PDU – Tested

cf56018b-5859-4fd5-8d30-6c31c1da329d copy
EE
90 Day
cf56018b-5859-4fd5-8d30-6c31c1da329d copy
EE
90 Day

Manufacturer

OEM Part Number

AP9567

GPS Part Number

AP9567

Categories

Tags

, , , ,

Price:

$262.99

Specifications
Voltage WPC AH/kVA Length Width Height Weight
100/120VAC N/A 1400 VA 24.02in 1.70in 1.70in 4.81lb
Voltage 100/120VAC
WPC N/A
Amp/H 1400 VA
Length 24.02in
Width 1.70in
Height 1.70in
Weight 4.81lb

APC NetShelter — Basic Rack PDU (AP9567)

This is the Tested Version.

SKU: PDU-APC-AP9567  | Type: 0U vertical, Basic (non-metered) rack PDU for 100/120 V single-phase racks. Delivers up to 1.4 kVA with 14 × NEMA 5-15R outlets; locking NEMA 5-15P input on a 12 ft (3.7 m) cord. Short vertical form factor (24 in) for compact racks.

  • Outlet set: 14 × NEMA 5-15R (120 V) for general IT loads.
  • Input: NEMA 5-15P; single 12 ft (3.7 m) line cord; 50/60 Hz.
  • Basic design: No local metering or switching — simple, reliable 120 V distribution.
  • Zero-U vertical: Toolless NetShelter brackets included; preserves rack U-space.
  • Data-center ready: UL/cUL & METI Denan; operating 32–113 °F (0–45 °C), 0–95% RH.

Technical Specifications — AP9567
Parameter Detail
PDU Type Basic; Zero-U vertical (0U)
Input 100/120 VAC; NEMA 5-15P; 1 power cord; length 12 ft (3.7 m)
Line Rated / Max Input Current 12 A line-rated  |  15 A input limit
Output Voltage 100/120 VAC
Outlets 14 × NEMA 5-15R
Load Capacity 1,400 VA
Frequency 50/60 Hz
Dimensions (H × W × D) 24.02 × 1.70 × 1.70 in (610 × 44 × 44 mm)
Net / Ship Weight 4.81 lb (2.18 kg)  |  ~6.44 lb (2.92 kg) packaged
Form Factor / Mounting 0U; rack-mounted; vertical; mounting location side; no preference
Included Hardware Installation guide; rack mounting brackets; toolless mounting kit
Certifications UL Listed; cUL Listed; METI Denan
Environment Operating: 32–113 °F (0–45 °C), 0–95% RH; Altitude 0–10,000 ft
Storage: −13–149 °F (−25–65 °C), 0–95% RH; Altitude 0–50,000 ft
Warranty (mfr.) 2-year repair or replace

Notes & Replacement

AP9567 is a short vertical Basic 0U PDU (no metering). Need a 120 V unit with a local amp display? See
AP7800B (1U, 8× 5-15R). Need a full-height 0U metered IEC model for 200/208 V? See AP8841 (30 A, 36× C13 + 6× C19).

Product Options — Tested vs. Refurbished PDUs
Option Description Warranty
Tested Cord/plug inspection; ground & continuity checks; load test across all 5-15R outlets; bracket fit verified. 90‑Day
Refurbished Cleaned and serviced; cosmetic touch-ups as needed; full outlet re-verification after service. 1‑Year

  • Use case: Simple 120 V distribution in compact or short racks (24″ vertical run).
  • Space: Zero-U mounting preserves 19″ rack units for gear.
  • Install tip: Observe 12 A continuous derate (80% of 15 A max) and secure cords with the included bracketry.

Compatibility & Variants Matrix — 120 V Rack PDUs
Model Input / Plug Outlets Rating / Notes
AP9567 100/120 V 1φ / NEMA 5-15P (12 ft) 14 × NEMA 5-15R Basic; 0U; 1.4 kVA; 12 A line-rated (15 A max).
AP9562 100/120 V 1φ / NEMA 5-15P (12 ft) 10 × NEMA 5-15R Basic; 1U; 1.4 kVA; shorter cord reach not required.
AP7800B 100/120 V 1φ / NEMA 5-15P (12 ft) 8 × NEMA 5-15R Metered; 1U alternative when local current display is needed.



Why buy from Gruber
  • Professionally tested — Outlets verified under load; ground/continuity checks documented.
  • Exact fit hardware — Ships with the correct Zero-U toolless brackets and install guide.
  • Fleet-ready — Standard 5-15R outlets for common 120 V IT gear.
