$716.99
| Voltage | WPC | AH/kVA | Length | Width | Height | Weight |
|---|---|---|---|---|---|---|
| 208 VAC | N/A | 3,300 VA | 35.51in | 2.20in | 1.73in | 6.46lb |
| Voltage | 208 VAC |
| WPC | N/A |
| Amp/H | 3,300 VA |
| Length | 35.51in |
| Width | 2.20in |
| Height | 1.73in |
| Weight | 6.46lb |
SKU: PDU-APC-AP8858NA3 Â |
Type: 0U vertical, Metered (2G) rack PDU for 200/208/230/240 V single-phase racks. Delivers up to 3.3 kVA with a local LCD (amps, volts, kW, kWh) and remote monitoring; outlet layout 18 × C13 + 2 × C19; locking NEMA L6-20P input on a 9.84 ft (3.00 m) cord.
| Parameter | Detail |
|---|---|
| PDU Type | Metered, 2G; Zero-U vertical (0U) |
| Input | 200/208/230/240Â VAC; NEMAÂ L6-20P; cord length 9.84Â ft (3.00Â m); 1 power cord |
| Line Rated / Max Input Current | 16 A line-rated  | 20 A input limit |
| Output Voltage | 208Â VAC |
| Outlets | 18 × C13  | 2 × C19 (total 20) |
| Load Capacity | 3,300Â VA |
| Frequency | 50/60Â Hz |
| Dimensions (H×W×D) | 35.51 × 2.20 × 1.73 in (90.2 × 5.6 × 4.4 cm) |
| Net / Ship Weight | 6.46Â lb (2.93Â kg) Â |Â Ship wt. ~10.85Â lb (4.92Â kg) |
| Included Hardware | Toolless rack mounting brackets; locking input power cord; serial configuration cable; installation & safety guides |
| Certifications | METIÂ Denan; VDE |
| Standards | UL 60950-1; CSA C22.2 No. 60950; IEC 60950 |
| Environment | Operating: 23–140 °F (−5–60 °C), 5–95% RH; Altitude 0–10,000 ft Storage: −13–149 °F (−25–65 °C), 5–95% RH; Altitude 0–50,000 ft |
| Warranty (mfr.) | 2-year repair or replace |
AP8858NA3 is a current half-height 0U Metered (2G) PDU (20 outlets, 20 A L6-20P). Need more outlets or 30 A capacity? See AP8841 (0U, 30 A, 36 × C13 + 6 × C19) or, for 3-phase mixed-voltage racks, AP8863 (0U, 20 A, 120/208 V 3φ).
| Option | Description | Warranty |
|---|---|---|
| Tested | Operationally verified: load checks on all C13/C19 outlets; cord/plug inspection; LCD metering verified; thresholds/alarm check. | 90‑Day |
| Refurbished | Cleaned and serviced unit; cosmetic touch-ups as needed; full outlet and meter re-verification after service. | 1‑Year |
| Model | Input / Plug | Outlets | Rating / Notes |
|---|---|---|---|
| AP8858NA3 | 200/208/230/240 V 1φ / NEMA L6-20P (9.84 ft) | 18 × C13; 2 × C19 | Metered 2G; 0U (half-height); 3.3 kVA; 16 A line-rated (20 A max). |
| AP8841 | 200/208 V 1φ / NEMA L6-30P (9.84 ft) | 36 × C13; 6 × C19 | Metered 2G; 0U (full-height); 5.0 kW; 24 A line-rated (30 A max). |
| AP8863 | 120/208 V 3φ / NEMA L21-20P | 24 × NEMA 5-20R; 6 × NEMA L6-20R | Metered 2G; 0U; mixed 120/208 V 3-phase distribution. |
