Manufacturer
OEM Part Number
GPS Part Number
Categories
$19.98
| Voltage | WPC | AH/kVA | Length | Width | Height | Weight |
|---|---|---|---|---|---|---|
| 277 V | N/A | 100 A | 1.7" | 0.8" | 2.5" | 0.20 lb |
| Voltage | 277 V |
| WPC | N/A |
| Amp/H | 100 A |
| Length | 1.7" |
| Width | 0.8" |
| Height | 2.5" |
| Weight | 0.20 lb |
Genuine Carling C-Series unit built with Delay Code “03”. Delay 03 is a switch-only configuration (no hydraulic-magnetic trip element). It provides panel ON/OFF switching in the C-Series form factor and should not be used where overcurrent protection is required.
| Parameter | Detail |
|---|---|
| Manufacturer | Carling Technologies |
| Series / style | C-Series, panel-mount toggle |
| Poles | 1 pole (single-pole break) |
| Current rating (In) | 100 A |
| Frequency / Delay code | 03 — 50/60 Hz, Switch-Only (no trip element) |
| Voltage capability (family) | UL Recognized: up to 480 VAC or 150 VDC (configuration-dependent) UL489 Listed: up to 240 VAC or 125 VDC (configuration-dependent) |
| Actuator | Handle / toggle (I-O or ON-OFF legend per build) |
| Terminations | High-current terminals per build code (e.g., 10-32 screw, studs). Note: terminals for >50 A follow high-amp codes. |
| Mounting | Panel mount; 6-32 threaded inserts (C-Series bezel) |
| Dimensions (H × W × D) | ≈ 63.5 mm × 19.1 mm × 42.0 mm (≈ 2.50 in × 0.75 in × 1.65 in) |
| Weight | ≈ 0.20 lb |
| Standards / approvals | UL / cUL (supplementary protector); IEC/EN 60934 (per marking). Switch-only — not a protective breaker. |
| Condition | Tested pull — cleaned, inspected, switching function verified; light cosmetic wear only |
| Option | What’s included | Warranty |
|---|---|---|
| Tested Switch | Cleaned, inspected; ON/OFF function verified; terminals checked; ready to install | 90-Day |
