$118.29
| Voltage | AH/kVA | Length | Width | Height | Weight |
|---|---|---|---|---|---|
| 460 V | 100 A | 5.1" | 3.3" | 5.5" | 3.31 – 4.41 lb |
| Voltage | 460 V |
| Amp/H | 100 A |
| Length | 5.1" |
| Width | 3.3" |
| Height | 5.5" |
| Weight | 3.31 – 4.41 lb |
Genuine AEG LC/LS-series power contactor professionally removed from a functioning system, then cleaned, inspected, and shop-tested. A fast, like-for-like replacement when uptime matters.
| Parameter | Detail |
|---|---|
| Manufacturer | AEG |
| Part number | LC57 • E-Nr 910-337-351-36 |
| Utilization category | AC-3 (motor duty) |
| Thermal current (Ith) | 100 A (conventional free-air) |
| AC-3 power (approx.) | ~30 kW @ 400/415 V • ~50 HP @ 460 V |
| Rated operational voltage (Ue) | Up to 600 V AC (per nameplate) |
| Coil (control circuit) | Per E-Nr suffix “-36” (factory coil code); LC/LS57 series commonly available in 120 V AC (-00) and 220–240 V AC 50/60 Hz (-50) variants — confirm on label |
| Poles & auxiliaries | 3 main poles; auxiliary block options (e.g., 2NO+2NC on “.22” variants) |
| Terminations | Screw clamp / bolt-lug style (per build) |
| Mounting | Panel mount; mechanical interlock kits available for reversing sets |
| Dimensions (H × W × D) | Approx. 140 mm × 85 mm × 130 mm (5.5 in × 3.3 in × 5.1 in) — LS/LC57 body class |
| Weight | ≈ 1.5–2.0 kg (3.31–4.41 lb) |
| Compliance | IEC/EN 60947-4-1; UL/CSA as marked |
| Condition | Tested pull — cleaned, inspected, verified; light cosmetic wear only |
| Option | What’s included | Warranty |
|---|---|---|
| Tested Pull | Cleaned, inspected, verified operation; intact labels; ready to install | 90‑Day |
