$9.24
| Voltage | WPC | AH/kVA | Length | Width | Height | Weight |
|---|---|---|---|---|---|---|
| N/A | N/A | N/A | N/A | N/A | N/A | .5 lbs |
| Voltage | N/A |
| WPC | N/A |
| Amp/H | N/A |
| Length | N/A |
| Width | N/A |
| Height | N/A |
| Weight | .5 lbs |
Connect two compatible current transformers to a single meter input with the Neurio W2 CT Y-Splitter. Part number 1622286-00-A combines measurements from two CTs monitoring the same electrical phase.
Useful for installations with multiple solar inverters or separate service feeds, this accessory supports metering arrangements where one CT cannot capture all the required conductors.
Designed for the Neurio W2 metering system used in compatible Powerwall 2 and Powerwall+ installations. Listing is for the splitter harness only; current transformers, meter, and extension cables are sold separately.
| Category | Detail |
|---|---|
| Product Name | Neurio W2 CT Y-Splitter |
| Part Number | 1622286-00-A |
| Required Meter | Neurio W2 Remote Energy Meter |
| Compatible CTs | Neurio W2 200 A CTs, 1622277-series |
| Connection Configuration | Two same-phase CT connections to one meter input |
| Combined Metering Capacity | Up to 400 A per input channel with two properly installed 200 A CTs in parallel; each CT remains limited to 200 A |
| Product Scope | Splitter harness only |
Use with compatible Neurio W2 equipment only. Neurio W1 accessories are not interchangeable with W2 components, and this splitter is not intended for the Tesla Remote Meter. Neurio metering is not supported with Powerwall 3. Installation should follow Tesla’s metering instructions, including correct CT orientation, phase matching, and meter configuration.
